TEMPLE
PROPOSAL AND CONCEPT
|
| |
| Sri. Bhavani Bagwati Mata Temple is
located in empty area of plot at survey no. C19, Bani
Park, Jaipur with opening towards west side, Plot is facing
road at two sides, Sawai Jaisingh Highway from south side
and (Bihar) Tulsi Marg from west side. One existing structure
is all ready placed at centre of the plot with open plot
at north side of size 135� X 85� for the new temple. Keeping
20� open space from all sides, we are getting 95� X 45�
rectangular plot from the new temple construction. |
|
| A Sat sang Hall is placed on ground
floor and Temple is planned on first floor. Temple is
planned west facing so that we will face east while praying
the statue. Basic concept is auspicious number 9 for Nav
Mata and Nav Graha. All the dimensions derived from No.9
with multiplication of 9 inches. No. 9 is most auspicious
in all nos. and is lucky for many peoples. |
|
| Temple Building
is with two floors structure. |
|
| A. GROUND FLOOR
: |
|
1.
|
|
Main grids, horizontal
and vertical are of 6�-9� (81�) with multiplication
of No. 9. |
|
2.
|
|
Entrance canopies
of 81” X 81” size are at two sides of
stair case. |
|
3.
|
|
Entrance lobby to
Satsang Hall of 13’-6” X 13’-6”
below stair case. |
|
4.
|
|
Right side of Entrance
is a lift to go up on first floor for old and disable
peoples. |
|
5.
|
|
Left side of entrance
is a small cabin type room for a care taker, who
will guide and keep watch on |
|
|
devotes coming for
Satsang hall. The room will be controlling room
for ground floor. |
|
6.
|
|
In Satsang hall is
one step higher to entrance lobby; of size 40’-6”
X 40’-6” with four sides corner cut
|
|
|
with area of 1200
sft which is sufficient for 125 to 150 devotees
seating. |
|
7.
|
|
One raised platform
of size 27’ x 6’-9” is provided
for program performance with provision of mike,
|
|
|
speaker, lights etc. |
|
8.
|
|
Two Nos. small rooms
as store rooms / green rooms with make-up arrangement
are planned behind |
|
|
stage platform. |
|
9.
|
|
Sat sang hall will
have two side entrances used as varanda (Platform)
which can be converted in |
|
|
balcony of size 13’-6”
X 6’-9” to accommodate 40 – 50
more devotes in future. |
|
|
|
|
|
|
|
|
| B. FIRST FLOOR : |
|
1.
|
|
Temple stairs: 3 flights
of 9 steps are provided to come up to first floor
temple entrance lobby of size |
| |
|
13’-6”
X 6’-9”. |
|
2.
|
|
At right side is a
lift for coming from ground floor. |
|
3.
|
|
At left side one small
room of size 6’-9” X 6’-9”
is provided and control / room for care taker. This
|
| |
|
room will have controlling
of music system for playing religious Bhakti Geet)
and arties etc. speaker |
| |
|
system is provided
in first floor temple and ground floor Satsang hall
with separate control. |
|
4.
|
|
Temple Sabha mandap
hall is one step higher to entrance lobby sabha
mandap with size of 40’-6” X |
| |
|
40’-6”
along with four balconies of size 13’-6”
X 6’-9” will accommodate around 150
devotees at |
| |
|
a time. |
| |
|
|
|
5.
|
|
Grabha Griha (Sanctum)
of size 13’-6” X 13’-6”
for placing Deity’s statue. Shri. Bagvamati
Bhawani |
|
|
Mata platform this
room is specially designed for Mataji’s main
statue where Mataji will be seating on |
|
|
lion riding toward
north and facing west. Devotees will face east while
praying Mata ji. In morning time |
|
|
it is always best
to face east while praying because we pray the rising
Sun god same time. Sun window, |
|
|
one circular window
opening will be kept east side of Garbha Griha with
marble carving jail shape and |
|
|
face of sun god with
his rays, Frosted glass is fixed in the window. |
|
|
|
|
|
Additional Deities :
A small Shree Ganeshji statue is at left side and Lord
Shiva statue at right side on the platform with small
shivliga in front of Lord Shiva Statue is placed along
with Mata ji statue. So our prayer will start from Shree
Ganeshji, then Mataji and last with Shivji. So we get
proper and maximum blessing by praying this way. |
| |
Exterior Finish :
Pink and Red colored sand stone cladding is designed from
all exterior sides and all domes / shikhars. Design of
exterior art work is sangam (combination) of all types
of Indian Temple architecture. Main Shikhar as North-West
type, Sabha Mandap pyramid is of North-East type, Entrance
half round domes, rounded projected chajjas, window jalis
& chajjas, (Zaroka) as Jaipur style of architecture
and some of relief work details / motifs are south Indian
architecture style. All these details are blended / combined
together to show complete Hindu (Indian) Temple architecture
beautifully. |
| |
Interior Work :
Interior of Sabha Mandap and Satsang hall is artistically
designed, carved and done in white marble. All walls have
many spiritual statues relief works and religious motifs.
False ceiling will be done artistically in plaster of
Paris material. Electrical light fittings and music system
will also have important role in this temple Vastu.
Maximum height of Temple Shikhar with Kalash will be 792”
(66 feet ) total of which is No. 9. Many other details
are designed to get positive waves and inspiration from
temple prayer. |
| |
Entrance Gate And Compound Developement
:
We have old water well at North-East corner of the plot;
which is auspicious for whole Temple project. We are trying
to enhance the spiritual importance of this well with
providing a beautiful pyramid shaped roof supported by
artistically carved sand stone pillars. This pyramidal
roof will generate and increase more energy in this well
water. We may have to increase depth of the well if it
is necessary.
Design of Entrance Gate and compound is designed in such
a way that, it will create spiritual atmosphere in and
around the temple Vastu (structure) so that devotes will
bow his head with respect while entering the temple. |
| |
| We are fully sure that the dream
project of your trust will fulfill your wishes and all
devotees and will get complete satisfaction of the life.
All we pray together for good
result and blessing of Mataji.
Jai Mata Di!
|
